BTSTC-AT017

BTSTC-AT017 anti-jamming antenna can receive GPS-L1, BDS-B1, GLO-L1, Gal-E1 and GPS-L5 satellite navigation signals at the same time, and can realize single system and joint positioning and navigation; It can realize the anti-jamming function of GPS-L1, BDS-B1, Glo-L1 and GPS-L5 signals.

cyj@btstc.com

Inquiry

Share to:

Category:

Products

GNSS

Anti-jamming Antennas

7 element AJ CRPA

Keywords:

Home page

BTSTC-AT017

Details

Key Features & Performance

Items	Performance
Receiving frequency points	GPS-L1、BDS-B1、Glonass-L1、Galileo-E1
Anti-jamming frequency points	GPS-L1、BDS-B1、Glonass-L1、Galileo-E1、GPS-L5
Antenna array element	4 GPS-L1, BDS-B1, Glonass-L1, Galileo-E1 array elements, 4 GPS-L5 array elements, 8 array elements in total
Anti-jamming capability	Single broadband ≥ 95 dB, three broadband ≥ 85 dB
Antenna gain	Elevation 90 degrees: ≥ 3dB
Cold start	≤50s
Positioning accuracy (1 σ)	≤10m
Speed measurement accuracy (1 σ)	≤ 0.2m/s (horizontal), ≤ 0.3m/s (elevation)
Maximum speed	≤2000m/s
Maximum acceleration	≤10g
Jerk	≤10g/s
Output protocol	NMEA4.1
Output frequency	1, 2, 5, 10Hz can be configured
Input voltage	18～36V
Power consumption	≤28W
Antenna weight	≤950g
Dimension	φ150mm×55mm
Environmental adaptability	Working temperature: -40 ℃ ~ 60 ℃ Storage temperature: -55 ℃ ~ 65 ℃
